Pylon Audio - Diamond 28 prestige - Pair

FINAL SALES - PYLON Diamond 28 first edition

The Diamond 28 is a 2,5 way, equipped with the widely appreciated 19mm Scan Speak textile dome was used, while the mid’s and the down’s of the band entrusted with a pair of 18cm transducers made by Norwegian Seas. By optimizing the selection of the tweeters transducers we have obtained sophisticated sustain of high frequencies, while mid-woofers, with light cellulose membrane allow for a lot of flexibility division band in the midrange. The whole results in a dynamic, coherent and retail nature of the presentation that is differentiating recordings well.

By a slight inclination of the design the desired visual effect was achieved, and it was combined with the optimization of the dependence phase that occur between the loudspeakers. In Diamond 28 the steering is mounted on technique direct mounting, it uses only polypropylene capacitors. Placement of coils is optimized to minimize interference.

Loudspeakers enclosures are made of solid MDF, which additionally were strengthened with inner rim. To suppress the sound bitumen mats and sheep's wool were applied. The loudspeaker was set on a pedestal, which in addition to providing aesthetic impressions, provides an anti-vibration platform for the loudspeaker set.

Diamond 28 is the unique combination of natural sounding with the look of the design.

The columns are dedicated for use in rooms with a floor area from 25 to 45 m2.

Technical Specifications

• Impedance: 4 Ohm
• Bandwidth: 36 Hz - 20 kHz
• Nominal power: 120 W
• Maximum power: 250 W
• Efficiency: 90 dB
• Dimensions [W x H x D]: 196 x 1040 x 370 mm
• Weight: 25 kg / piece
• Woofer: 2 x Pylon Audio PSW 18.8.CA (2xSeas CA18RLY)
• Tweeter: Pylon Audio PST 19.T (Scan Speak D2010/851300)
• Spikes + stand: Yes
• Speaker grille: Yes, magnetic
• Warranty: 4 years

FINAL SALES - PYLON Diamond 28 first edition
