mission ZX-12 SUB

High Power Amplifier

The built-in amplifier is optimized for high impact at low frequencies. The fast response and high-power performance is perfect for movies or music.

No-Presses Paper Cones

A specially engineered 12” paper cone with increased self-damping properties offers an increased structural rigidity of the cone itself for a fuller performance and massive bass impact.

Copper Lined Vents

Reduce the magnetic distortion and also offers improved heat dissipation, letting the ZX-12 SUB rumble for hours but remain cool.

Low Pass Filter Slope

Continuously adjustable from 35Hz to 120Hz (@33dB) for seamless acoustic integration with your speaker’s performance.

High Sensitivity & Versatility

Low level inputs, output connections and a dedicated LFE input are provided. Additionally, the auto power sensor is sensitive enough to detect incoming signals of extremely low level for automatic activation of the subwoofer when required.

ZX-12 Sub Specifications

• Drive Units- 1 x (12") 300 mm cone long-throw
• Frequency Response- 35- 120 Hz (+-±3dB)
• Amplifier Power Output- 300 W
• Peak Power Output- 450 W
• Line Input Sensitivity- 200mV for maximum output
• Crossover Range- 30 - 150 Hz
• Inputs- Stereo line in (2 x RCA phono)
• Mono (LFE) line in (RCA phono)
• Input Impedance- Line input 10 k
• LFE- 5 kOhms
• Signal-to-noise Ratio (s/n) ≥ 85 dB
• Avg. Max Output @1m- 118 dB
• Features- Phase inversion, auto on-off
• Dimensions- Height: (420+58) mm (with feet)
• Width: 400 mm
• Depth: (450+15) mm
• Net Weight: 23 kg
